Major Features

• Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B) identifiers.
• CAN messages are time-stamped with 2 microseconds resolution.
• Two high-speed CAN channels (compliant with ISO 11898-2), 10kbit/s up to 1 Mbit/s
• Connect Eagle to a PC to configure bit rates, trigger conditions and filters using Kvaser’s CANlib or Kvaser Memorator Tools.
• Kvaser Eagle's script functionality, allowing users to develop highly customised t-script applications written in the Kvaser t programming language.
• Encryption of scripts to protect intellectual property.
• Plug and play installation, and a comprehensive user guide to help make t script development quick and easy.
• Three built-in microprocessors (MCUs) that ensure real-time CAN bus performance. One MCU is used to handle each CAN channel and another MCU handles the script, ensuring that Eagle can also handle very large and complex scripts.
• 200MHz processor performance with minimal current consumption.
• Large on-board RAM buffer for CAN messages and flashing LED light to alert the user to the buffer being overrun.
• Higher level protocols such as ISO 15765 and J1939 can be implemented in t-script. Working sample code for ISO 15765-2 is already included.
• Fully compatible with J1939, CANopen, NMEA 2000® and DeviceNet.

Filters

• Log continuously, or logging can be triggered by creating advanced triggers based on messages, data signal values, error messages, external trigger's falling or rising edge, and I/O signals.
• Pre- and post-triggers are available without buffer size restrictions, limited by disk space only.
• Filter out selectable messages and/or signals to be logged. The identifiers can be picked from a database, or all messages can be logged.
• Support for pass as well as stop filters.
• Create a counting pass filter to have a message logged at enumerated occurrence.
• Handles up to 20,000 msgs/s in standalone logger mode.
• External digital output that can drive an LED or a buzzer.
• Supports Silent Mode - Log bus traffic safely without interfering and "listen-only" mode for bus analysis tools.

Memory Cards and Functions

• Supports SD and SDHC memory card formats.
• Set up several devices in a daisy chain for larger logging capacity.
• Configuration Software in the PC
• Easy to use graphic configuration tool - Memorator Tools.
• Configuration of the CAN controller, i.e. bit rate and filters.
• Configuration of the trigger conditions.
• Configuration of filter for messages to be stored.
• Configuration upload and download via USB.
• Using the included Kvaser Dispatcher software, a complete measurement setup can be turned into a self-installing package that is sent to a remote location to carry out a specific logging task.

Warranty

• 2-Year Warranty. See our General Conditions and Policies for details.

Support

• Free Technical Support on all products available by contacting support@kvaser.com

Software

• Documentation, software and drivers can be downloaded for free at www.kvaser.com/downloads.
• Kvaser CANLIB SDK is a free resource that includes everything you need to develop software for the Kvaser CAN interfaces. Includes full documentation and many program samples, written in C, C++, C#, Delphi, and Visual Basic.
• All Kvaser CAN interface boards share a common software API. Programs written for one interface type will run without modifications on the other interface types!
• J2534 Application Programming Interface available.
• RP1210A Application Programming Interface available.
• On-line documentation in Windows HTML-Help and Adobe Acrobat format.
